Honeywell ST 3000 Installation Guide

5.1 Wiring Diagrams and Dimension Drawings, Continued
Dimension Drawings - Series 100 and Series 900, Continued
Transmitter Type and
Key Number
Table Selections
Mounting
Drawing Number
**STR_ _ _
Table II
Flush Flange 3.5” diaphragm _ _ _A_ _ _ _ _ _ _ _ – 51305141-000
Off Line Flange 2.4” diaphragm _ _ _B _ _ _ _ _ _ _ 51305138-000
Off Line Flange 2.9” diaphragm _ _ _C _ _ _ _ _ _ _ _ 51305139-000
Off Line Flange 4.1” diaphragm _ _ _D _ _ _ _ _ _ _ _ 51305140-000
Extended Flange 2.9” diaphragm _ _ _E _ _ _ _ _ _ _ _ 51305137-000
Extended Flange 3.5” diaphragm _ _ _F_ _ _ _ _ _ _ _ 51305137-000
Pancake Seal _ _ _G_ _ _ _ _ _ _ _ 51305144-000
Chemical Tee “Taylor” Wedge _ _ _H_ _ _ _ _ _ _ _ 51305144-000
Threaded Connection 2.4”
diaphragm
_ _ _J_ _ _ _ _ _ _ _ 51305148-000
Threaded Connection 2.9”
diaphragm
_ _ _K_ _ _ _ _ _ _ _ 51305148-000
Threaded Connection 4.1”
diaphragm
_ _ _L_ _ _ _ _ _ _ _ 51305148-000
Sanitary Seal 1.9” diaphragm _ _ _M_ _ _ _ _ _ _ _ 51305143-000
Sanitary Seal 2.4” diaphragm _ _ _N_ _ _ _ _ _ _ _ 51305143-000
_ _ _P_ _ _ _ _ _ _ _ 51305143-000
Sanitary Seal 4.1” diaphragm _ _ _Q_ _ _ _ _ _ _ _ 51305143-000
Saddle Seal _ _ _R_ _ _ _ _ _ _ _ 51305142-000
Sanitary Seal 2.9” diaphragm
50 ST 3000 Release 300 Installation Guide 2/05

Honeywell ST 3000 Specifications

General

Manufacturer	Honeywell
Category	Transmitter
Stability	±0.01% of URL per year
Operating Temperature	-40 to 85°C (-40 to 185°F)
Communication Protocol	HART
Housing Material	Aluminum or Stainless Steel
Enclosure Rating	IP66/67, NEMA 4X
Measurement Type	Gauge, Absolute, Differential
Output Signal	4-20 mA, HART
Process Temperature	-40 to 121°C (-40 to 250°F)
Hazardous Area Approvals	FM, CSA, ATEX, IECEx
Process Connection	1/2" NPT
Material	316L Stainless Steel, Hastelloy C
