INTRODUCTION
Purpose of this manual
This manual details how to install and maintain a TS2 device.
Details on operating instruction, plant maintenance and
troubleshooting are also provided.
What TS2 is?
TS2 is a Temaline device acting as controller in the Temaline
architecture.
TS2 managed applications include: Access Control,
Time&Attendance, Canteen, light Intrusion detection and Lift.
It can manage up to 16 doors (with reader on a single side of the
door or with reader on both sides of the door.
It can also manage up to 64 supervised inputs and 64 Digital
Output.
It is connected to the Supervisor via Ethernet line. It manages all
the field devices via LonWorks bus.
System Architecture
Figure 1 shows a typical system architecture in which the TS2 is
inserted.
Other devices represented are:
• TemaPower: is the power supply used to supply the
devices. It can be one Temaline TPU-xx device or a third
party power supply.
• Temaline RTU devices: Fields devices used for the
management of the doors.
The connections shown are:
• The Ethernet connection: it connects EBI supervision
center with all the peripheral devices and peripheral device
in peer to peer.
• The Power supply connection: it connects the Power
Supply device with other Temaline devices.
