User System Setup (cont’d)
29
System Information
To view the current software/firmware version installed on your system, do the following:
ICON ACTION NOTES
1. From the "Home" screen, press the Setup
icon.
2. Press the System Info icon.
The Interface Name, Host Name, MAC Address,
CRC, IP Address, Broadcast Address, and
NetMask are also displayed.
Keypad Reset
To access Keypad Reset do the following:
ICON ACTION NOTES
1. From the "Home" screen, press Setup and
the System Setup icon.
2. Press the Advanced Setup icon.
3. Enter your Authorized Code.
4. Press the Keypad Reset icon.
When the Keypad Reset icon is pressed, the
message is displayed:
Confirmation
Are you sure you want to reset?
Select Yes or No.
Advanced Setup
The Advanced Setup screen allows access to Keypad Reset, Keypad Test, Night Setup and Output
Setup menus.
Keypad Test
A series of diagnostic tests are provided that allows verification of correct operation of the keypad and
its connections to the security system. There are a total of five diagnostic tests; LCD Display Test,
Audio Test, LED Test, Calibration Test, and Z-Wave Test.
Performing Diagnostic Tests
Select any diagnostic test from the “Diagnostics” screen by pressing its associated Test icon. All or any
individual test may be run when you access the “Diagnostics” screen; however, each test must be
performed one at a time. At any time when a test is not being performed, you can press:
• back to return to the previous screen, or
• home to return to your home page.
Once the Diagnostics screen is exited, subsequent entry to this screen displays all test options as
"Not Performed."
LCD Display Test
Perform the LCD Display Test as follows:
ICON ACTION NOTES
1. Press the Advanced Setup icon.
2. If applicable, enter your Authorized Code.
3. Press the Keypad Test icon.
4. Press the LCD Display Test icon; a series of
screens appear.
After each type of display, you are asked if
the display was proper.
The Emergency screen cannot be
accessed while running the LCD
Display Test.
If the response to all questions is yes, the LCD
Display Test message area of the Diagnostics
screen displays “Passed”.
Audio Test
