Important Notes (Cont’d)
46
Effects of Home Construction on Wireless Range between Z-Wave Enabled Devices
Note: The distances shown in the table below are typical examples. Actual performance in your home will
vary.
From the Remote (or repeating Z-Wave module) to the destination device:
Number of Walls
or Obstacles
Plastic J-Boxes* Metal J-Boxes Plastic J-Boxes* Metal J-Boxes
0** 100 ft 80 ft 100 ft 80 ft
1 70 ft 56 ft 60 ft 48 ft
2 49 ft 39 ft 36 ft 29 ft
3 34 ft 27 ft 21 ft 17 ft
* For Plug-in modules or in-wall devices installed in plastic junction boxes.
**Line of sight / no obstructions.
Z-Wave devices are identified by the Z-Wave logo and can be purchased from your local
retailer.
Z-Wave
®
is a registered trademark Sigma Designs, Inc. and/or its subsidiaries.
U
L
CO annunciation has not been investigated by UL and may not be used for UL installations.
