Parameters accessible with Function Codes 04
32 UDA2182 Communications User Guide January 09
Address
(hex)
Register
(decimal)
Parameter Name Type Notes
0020 30033
Logic 3 output
Long
0022 30035
Logic 4 output
Long
0024 30037
Output 1
Float
0026 30039
Output 2
Float
0028 30041
Output 3
Float
002A 30043
Relay 1 state
Long
002C 30045
Relay 2 state
Long
002E 30047
Relay 3 state
Long
0030 30049
Relay 4 state
Long
0032 30051
PID 1 PV
Float
0034 30053
PID 1 SP
Float
0036 30055
PID 1 Auto/Manual
Long 0 = auto; 1 = manual
0038 30057
PID 1 Output
Float
003A 30059
PID 2 PV
Float
003C 30061
PID 2 SP
Float
003E 30063
PID 2 Auto/Manual
Long 0 = auto; 1 = manual
0040 30065
PID 2 Output
Float
0042 30067
Digital Input 1
Long
0044 30069
Digital Input 2
Long
0046 30071
Input 1 fail
Long 0= no failure; 1= failure
0048 30073
Input 2 fail
Long 0= no failure; 1= failure
004A 30075
Input Sum
Float Input 1 + Input 2. Input types the
same.
004C 30077
Input Differnece
Float Input 1 – Input 2. Input types the
same.
004E 30079
Input Ratio
Float Input 1 / Input 2. Input types the
same.
0050 30081
Percent Passage
Float 100 * Input 1 / Input 2. Input types
the same
0052 30083
Percent Rejection
Float 100 * (1 – Input 1/ Input 2). Input
types the same.
0054 30085
Cation Conductivity
Float Both inputs are conductivity type.
0056 30087
Input 1 US Pharmacopia uS / cm
monitored Value
Float Input 1 Conductivity
0058 30089
Input 1 US Pharamacopia Sensor
monitored Temperature Value
Float Input 1 Conductivity
