The OCS implements the following sequence to execute the AutoLoad function:
Power up OCS
Application Program absent
or
Application Program corrupted
AutoLoad
Enabled?
AUTOLOAD.PGM present in
the RM of the device ?
AutoLoad initiated.
OCS put in IDLE mode
AutoLoad run sequence
failed (with reasons for
failure)
NO
NO
YES
YES
AutoRun
Enabled?
OCS put in RUN Mode
OCS put in IDLE Mode
NO
YES
Figure 16.8 – Flow Chart for AutoLoad
