HORNER HE-XE1E2 - XLT System Menu; Figure 09.2 - XLT System Menu

MAN0878-09-EN_XLE_XLT_UserManual
A u g u s t 2 3 , 2 0 1 8 P a g e 50 | 158
XLT System Menu
Sub-Menus
Sub-Menus
Network Ok? Yes
Network ID: 253
Network Baud: 125 KB
( Use  to adjust )
Contrast: 
(Use  → to adjust)
Model: XTxxxx
Mode: Idle
Scan Rate(mS): 0.0
Lcl Net Use(%): 0.0
All Net Use(%): 0.0
Ladder Size: 2
Config Size: 8
Graphics Sz: 8
String Size: 8
Bitmap Size: 8
Text Size: 8
Font Size: 8
Protocol Sz: 8
SMS Msg Sz: 8
Firmware Rev: 11.59
CPLD Rev: 1.5
Self-Test: Ok
System RAM: Ok
System BIOS: Ok
Firmware: Ok
Logic Error: Ok
User Program: Ok
User Graphics: Ok
W-Dog Trips: 0
Net Errors: 0
Network State: Ok
Network ID: Ok
Dup Net ID: Ok
Clock Error: Ok
I/O System: Ok
Battery: Ok
Slot 1:+I/O: XTxxx
Slot 2:+I/O: XTC
Beeper Enable: Yes
( Use  to adjust )
Set Network ID
Set Network Baud
Set Contrast
View Status
View Diags
View I/O Slots
View Protocols
Set Fkeys Mode
Set Serial Ports
Set Time/Date
Set Beeper
Set Screen
Removable Media
Fail – Safe System
Clone Unit
(ESC to Exit)
Backup/Restore Data
Enable AutoRun
Enable AutoLoad
(ESC to exit)
Port 1:
(None Loaded)
Port 2:
(None Loaded)
Fkeys: Momentary
Sys-Fn enable: Yes
( Use  to adjust )
Dflt Pgm Port MJ1-232
MJ1 RS485 Bias No
MJ2 RS485 Bias No
Set Ethernet (Enet)
( Use  to adjust )
Addr: 192.169.254.128
Mask: 255.255.255.0
Gtwy: 0.0.0.0
( Reset required to )
( enable changes )
Time: 10:21:36
Date: 22-Jun-2007
Day: Thursday
( Use  to adjust )
( each field )
Saver enable: Yes
Timeout(min): 15
Popup Status: Off
Update Time(mS): 5
Max. graphics time
In the log scan.
Media Directory
No Card
XLT
System Menu
Figure 9.2
