Hospira Plum A+ - Equipment Description; Front Panel Display and Keypad

Plum A+
®
Infusion Systems
430-95597-001 (Rev. 06/05) 3- 1
SECTION 3
Equipment Description
Front Panel Display and Keypad
Back
Prime
Options/
Vol Inf
AB
Line A Flow
Indicator
Status Region
Working Region
Message Region
Status
Region
Working
Region
Message
Region
Start and
Stop Keys
Charging/
Line
Indicator
ON/OFF
Key
Line B Flow
Indicator
LCD
Battery
Charge
Indicator
Numeric
Keys
(Up/Left)
Selection
Key
(Down/
Right)
Silence
Key
Numeric Field
Clear Key
Decimal Point
Key
Softkey Label
Softkey
Selector
