Hotone AMPERO MINI User Manual

Customizing Your Ampero Mini
Module Edit Menu
Use the module control panel to edit or turn the current module on/off.
Select an effect from the effects list.
The parameter panel shows the adjustable parameters of the effect selected.
If the selected effect has more than three adjustable parameters, there will be an arrow at the right of the parameter panel. Press the arrow to see
the other parameters.
Slide on the three quick adjust paras or tap +/- buttons to adjust the parameters.
For more information on modules, effects, and parameters. See page 18.
Reminder: In some extreme cases the signal processor may become overloaded and display a “System Overload” caution.
DES I G N IN S P IRAT I ON
Parameter2 Parameter3Parameter1
Taptoseeotherparameters
(appearsonlywhenmorethan
3parametersareavailable)
Taptoseeotherparameters
(appearsonlywhenmorethan
3parametersareavailable)
Slidetocheckavailableeffects
Taptoselect
Effectslist
Nextmodule
Current patch number, patch name
Go back to patch edit menu
Previousmodule
Taptoturnthemoduleon/off
Entersavescreen
8
Control Settings
Use the control settings to determine the CTRL function and quick access para targets, setup the expression pedal parameters, and calibrate the
expression pedal.
Remember that all the control settings will change as you change patches. If you switch patches or turn Ampero Mini off before saving your
changes, the changes will be lost.
Make sure to press SAVE on the upper right of the display screen to save your settings.
Press CTRL on the main menu to enter the control menu.
Make selections from the right and left panels.
Like the effects module parameter menu, the selection panel features three adjustable options. These options will change according to the current
menu option.
If the selected menu has more than three adjustable options, there will be an arrow at the right of the selection panel. Press the arrow to see the
other options.
Current patch number
Exitthemenu
Entersave screen
Sub menu
Taptoselect
Optionspanel
Mainmenu
Tap to select
Option2
Option3Option1

Hotone AMPERO MINI Specifications

Digital Audio Specifications

digital audio signal processing	24-bit depth, 44.1kHz sample rate
dynamic range (DNR)	Max. 112dB (DA)
impulse response/IR processing	Supports 24-bit/44.1kHz Mono WAV files, 1024 points

Effects and Patches

effects	199
effects modules	Total of 9 simultaneous
patches	198 (99 user patches, 99 factory patches)

Looper and Drum Machine

looper time	Mono 100 seconds, Stereo 50 seconds
internal drum machine	100 Rhythm Patterns

Inputs and Outputs

inputs	One 1/4" TS Instrument jack, One 1/8" Stereo Aux In jack, One 1/4" TRS Expression Pedal input jack
outputs	One 1/4" TRS Unbalanced Stereo output jack, One 1/8" Stereo headphones output jack
usb port	USB 2.0 Type-C port, supports USB Audio 2.0

Resistance

instrument input resistance	4.7MΩ
aux in resistance	10kΩ
output resistance	1kΩ

Display

screen size	4"
display resolution	800 x 480
display type	Color Dynamic Display Touch Screen

Power Requirements

power requirements	9V DC Center Negative
current consumption	500mA Max

Weight and Dimensions

dimensions	134mm (W) x 120mm (D) x 49mm (H)
weight	529g
