Hotone AMPERO MINI User Manual

Definitions
Module
Ampero Mini supports the simultaneous use of up to 9 effects. Each
is called an “effects module”, or simply “module”. There are several
effects available in each module.
Parameter
Variables that determine the application of an effect are called
“parameters”. If we imagine each module as a separate effect pedal,
then each parameter would be a knob on that pedal.
Panel
1. Display Screen: Displays Ampero Mini’s current status. Use the
touchscreen to select effects, edit patches, and make tone
adjustments.
2. Footswitch: Use to change patches, turn on/off effects, set tap
tempo, etc.
3. EXP/CTRL (FS 3/4): 1/4" TRS input, for connecting an external
expression pedal/footswitch controller.
Perfect for Hotone Ampero Press or Ampero Switch.
4. INPUT: 1/4" Mono input connection for both electric/acoustic
instruments.
5. OUTPUT: Unbalanced 1/4" TRS stereo output connection to
amplifiers or other equipment. For stereo connection, a Y cable is
needed to split L/R output channels (Tip=Left channel, Ring=Right
channel).
6. PHONES: 1/8" stereo output for connecting headphones.
7. AUX IN: 1/8" stereo input for connecting external devices
(phone, MP3 player) for practice and jamming.
8. Adjusts the overall volume of all output Volume Knob:
connections.
9. USB: USB 2.0 Type-C jack for connecting to your computer.
10. Power Supply Connection: Plug in the attached power supply
(9V DC center negative) to turn the unit on.
Patch
The ON/OFF status of each module and the parameter settings are
stored in units called “patches”. These are your “tones”. Use patches
to recall, edit, and save your favorite tones.
Bank
A set of 3 patches is called a “bank”. Ampero Mini has a total of 66
banks, including 33 editable player (user) banks and 33 factory banks
(F01-F33), which can be adjusted by not saved.
2
DES I G N IN S P IRAT I ON
1
2 2
3 4 5
6
7
8
9
10
Left channel
Right channel
Blue stands for left channel (tip),
and red stands for right channel (ring)

Hotone AMPERO MINI Specifications

Digital Audio Specifications

digital audio signal processing	24-bit depth, 44.1kHz sample rate
dynamic range (DNR)	Max. 112dB (DA)
impulse response/IR processing	Supports 24-bit/44.1kHz Mono WAV files, 1024 points

Effects and Patches

effects	199
effects modules	Total of 9 simultaneous
patches	198 (99 user patches, 99 factory patches)

Looper and Drum Machine

looper time	Mono 100 seconds, Stereo 50 seconds
internal drum machine	100 Rhythm Patterns

Inputs and Outputs

inputs	One 1/4" TS Instrument jack, One 1/8" Stereo Aux In jack, One 1/4" TRS Expression Pedal input jack
outputs	One 1/4" TRS Unbalanced Stereo output jack, One 1/8" Stereo headphones output jack
usb port	USB 2.0 Type-C port, supports USB Audio 2.0

Resistance

instrument input resistance	4.7MΩ
aux in resistance	10kΩ
output resistance	1kΩ

Display

screen size	4"
display resolution	800 x 480
display type	Color Dynamic Display Touch Screen

Power Requirements

power requirements	9V DC Center Negative
current consumption	500mA Max

Weight and Dimensions

dimensions	134mm (W) x 120mm (D) x 49mm (H)
weight	529g
