Hotone AMPERO MINI User Manual

Using the Screen
Touch operation
Changing patches and editing settings can all be done with the touchscreen. You can also slide on the parameters to adjust them.
The “+/-” buttons will appear by pressing a parameter, as below:
Click “+/-” buttons to adjust the parameter (or press and hold for quick adjustment).
The “+/-” buttons will disappear if it is not operated for a period of time or press the current parameter again.
DES I G N IN S P IRAT I ON
4
Ampero Mini Tools
Ampero Mini is equipped with some great tools to expand your playing experience: a tuner, drum machine, looper and CTRL function.
TUNER
In default mode, pressing 1 and 2 footswitchs together will open the tuner.
Exit tuner
Pitchflat
Pitchsharp
Intune
Indicatesthecurrentnotename
SelectstunermodeAdjuststhepitchcalibration
On the upper part is a scale that indicates your pitch. Left of center is
flat, and right of center is sharp. As you tune your instrument towards
the middle, the color of the scale will change from red (out of tune) to
yellow (near pitch) to green (in tune).
Use REF PITCH to adjusts the pitch calibration ranging from 432Hz to
447Hz. Standard pitch is set at 440Hz.
MODE lets you select the tuner mode from Thru (for signal through),
Bypass (bypass tuning) or Mute (for silent tuning).
You can exit the tuner either by pressing any footswitch or by
pressing the Back button on the touchscreen.

Hotone AMPERO MINI Specifications

Digital Audio Specifications

digital audio signal processing	24-bit depth, 44.1kHz sample rate
dynamic range (DNR)	Max. 112dB (DA)
impulse response/IR processing	Supports 24-bit/44.1kHz Mono WAV files, 1024 points

Effects and Patches

effects	199
effects modules	Total of 9 simultaneous
patches	198 (99 user patches, 99 factory patches)

Looper and Drum Machine

looper time	Mono 100 seconds, Stereo 50 seconds
internal drum machine	100 Rhythm Patterns

Inputs and Outputs

inputs	One 1/4" TS Instrument jack, One 1/8" Stereo Aux In jack, One 1/4" TRS Expression Pedal input jack
outputs	One 1/4" TRS Unbalanced Stereo output jack, One 1/8" Stereo headphones output jack
usb port	USB 2.0 Type-C port, supports USB Audio 2.0

Resistance

instrument input resistance	4.7MΩ
aux in resistance	10kΩ
output resistance	1kΩ

Display

screen size	4"
display resolution	800 x 480
display type	Color Dynamic Display Touch Screen

Power Requirements

power requirements	9V DC Center Negative
current consumption	500mA Max

Weight and Dimensions

dimensions	134mm (W) x 120mm (D) x 49mm (H)
weight	529g
