APPENDIX E: GAS PRESSURE-SWITCH ADJUSTMENT
84 SERVICE MANUAL
Pressure-switch table OFF->ON
Oven types RPM Tolerance
1.06 3100 ±100
1.10 2300 ±100
1.20 2300 ±100
2.06 2800 ±100
2.10 2300 ±100
2.20 2300 ±100
9. If the registered value is lower than the value in the table, you have to adjust
thepressure switch clockwise. ½ turn adjusts approximately 150 RPM.
10. If the registered value is higher than the value in the table, you have to adjust
thepressure switch counter-clockwise. ½ turn adjusts approximately 150 RPM.
11. When you have completed the adjustment, turn the controller OFF and ON.
12. Turn on the gas inlet.
