Service cover
Description Spare part number
Service cover (includes 2 captive Phillips screws, secured by C-rings) 785288-001
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 25).
Remove the service cover:
1. Loosen the two captive Phillips screws (1) that secure the service cover to the computer.
2. Lift the rear edge of the cover (2) up and forward until it rests at an angle.
3. Remove the service cover (3) by sliding it up and back at an angle.
Reverse this procedure to install the service cover.
26 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
