Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket, hard drive connector cable, or
screws. These components are included in the Hard Drive Hardware Kit, spare part number 740706-001.
Description Spare part number
500-GB, 5400-rpm, 7.0-mm 669299-005
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 25), and then remove the following components:
a. Service cover (see Service cover on page 26)
b. Keyboard (see Keyboard on page 32)
c. Top cover (see Top cover on page 39)
d. Audio/USB board (see Audio/USB board on page 45)
Remove the hard drive:
1. Lift the right edge of the hard drive (1) until it rests at an angle.
Component replacement procedures 47
