Keyboard
NOTE: The keyboard spare part kit includes a keyboard cable.
Description Spare part number
For use in Canada 785871-DH1
For use in Latin America 785871-161
For use in United States 785871-001
Before removing the keyboard, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 25).
Remove the keyboard:
1. Position the computer with the front toward you.
2. Remove the two Phillips PM2.5×6.5 screws that secure the keyboard to the computer.
3. Open the computer.
4. Rest the computer on its left side.
32 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
