Reverse this procedure to reassemble and install the hard drive.
System board
NOTE: The system board spare part kit includes an Intel Celeron N2840 2.16-GHz (turbo up to 2.25-GHz)
processor (1333-MHz FSB, 2.0-MB L2 cache, dual core, SDP, 4.5 W), a UMA graphics subsystem, and
replacement thermal material.
Description Spare part number
Equipped with 2.0-GB of on-board system memory and the Windows 8 Standard operating system 800529-501
Equipped with 2.0-GB of on-board system memory and a non-Windows 8 operating system 800529-001
Equipped with the Windows 8 operating system 800527-501
Equipped with a non-Windows 8 operating system 800527-001
Before removing the system board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 25), and then remove the following components:
a. Service cover (see Service cover on page 26)
b. WLAN module (see WLAN module on page 28)
c. Optical drive (see Optical drive on page 30)
d. Keyboard (see Keyboard on page 32)
e. Top cover (see Top cover on page 39)
f. Audio/USB board (see Audio/USB board on page 45)
g. Hard drive (see Hard drive on page 47)
When replacing the system board, be sure that the following components are removed from the defective
system board and installed on the replacement system board:
●
Memory module (see xxx)
●
Hard drive connector cable (see xxx)
●
Power connector cable (see Power connector cable on page 60)
●
RTC battery (see RTC battery on page 54)
●
Fan (see Fan on page 56)
●
Heat sink (see Heat sink on page 58)
Remove the system board:
1. Disconnect the display panel cable (1) from the system board.
50 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
