HP StorageWorks 2000i G2 Modular Smart Array User Guide 49
Are both drive module LEDs off (Online/Activity and Fault/UID)?
Is the drive module Fault/UID LED blinking amber?
Is a connected host port’s Host Link Status LED off?
Answer Possible Reasons Actions
Yes • There is no power.
• The drive is offline.
• The drive is not
configured.
• Check that the drive is fully inserted and latched in place,
and that the enclosure is powered on.
Answer Possible Reasons Actions
No, but the
Online/Activity
LED is blinking.
The drive is rebuilding. No action required.
CAUTION: Do not remove a drive that
is rebuilding. Removing a drive might
terminate the current operation and
cause data loss.
Yes, and the
Online/Activity
LED is off.
The drive is offline. A predictive failure
alert may have been received for this
device.
• Check the event log for specific information
regarding the fault.
• Isolate the fault.
• Contact an authorized service provider for
assistance.
Yes, and the
Online/Activity
LED is blinking.
The drive is active, but a predictive
failure alert may have been received
for this device.
• Check the event log for specific information
regarding the fault.
• Isolate the fault.
• Contact an authorized service provider for
assistance.
Answer Possible Reasons Actions
No System functioning properly. No action required.
(see Link LED note: page 38)
Yes The link is down. • Check cable connections and reseat if necessary.
• Inspect cables for damage.
• Swap cables to determine if fault is caused by a
defective cable. Replace cable if necessary.
• Verify that the switch, if any, is operating properly. If
possible, test with another port.
• Verify that the HBA is fully seated, and that the PCI slot is
powered on and operational.
• In SMU, review event logs for indicators of a specific
fault in a host data path component.
• Contact an authorized service provider for assistance.
• See Isolating a host-side connection fault on page 53.
