HP 5300A - Digital Recorder Output; Portable Operation

b. Turn the 5300A right-side up with front-
panel facing you (ON-OFF-SAMPLE RATE on left
side) and slide the side-casting latches all the way to
the rear of the unit. The latch handles must be
pressed gently away from the center of the unit to
“unlock” them before sliding rearward.
c. With latch handles fully extended rearward,
mate the 5300A to the plug-on by placing the 5300A
on top of the plug-on.
d. With the latches fully extended rearward and
the 5300A properly positioned on the plug-on, an
equal space should be visible (about 1/8-inch wide)
where castings meet.
In the following step, DO NOT force
latches forward; if difficulty is encoun-
tered, check latches and castings for
obstructions.
e. Press down gently on top of 5300A casting and
push the left and right latches forward. Castings will
be brought together.
f. Check the position of the latches to ensure
that castings are properly mated and latched. When
properly latched, latches should not protrude past
rear-edge of casting and there should be a paper-thin
space between plug-on and 5300A.
g. To separate the 5300A from the plug-on, pull
the two-side casting latches fully rearward, (again it
is necessary to press the latch handles gently away
from the center of the instrument to unlock them).
h. When latches are fully extended rearward,
the 5300A and plug-on castings should be separated
by about 1/8-inch.
i. Lift 5300A gently away from plug-on.
2-13. DIGITAL RECORDER OUTPUT
2-14. To supply the 5300A Measuring System display
information to HP Models 5050B and 5055A Digital
Recorders, the HP 10533A Recorder Interface cable
must be used. The cable converts the serial-form data
from the 5300A to parallel-form data for processing
by the digital recorders. The HP 10533A Recorder
Interface cable is listed in Tables 1-2 and 1-5 as an
available accessory. Documentation is also included
in Section IV through VIII of this manual.
2-15. PORTABLE OPERATION
2-16.
The
HP
Model
5310A
Battery
Pack
enables
the
Measuring
System
to
be
used
in
areas
removed
from
ac
power
sources.
The
Battery
Pack
provides
up
to
8
hours
portable
operating
time
before
recharging.
Tables
1-2
and
1-4
list
the
HP
5310A
Battery
Pack
as
an
available
accessory.
Documentation
is
also
in-
cluded
in
Sections
IV
through
VIII
of
this
manual.
Model 5300A
Installation
2-17.
To
prepare
the
5300A
for
portable
operation,
turn
POWER
to
OFF
(full
ccw),
disconnect
ac
power
cord,
refer
to
Figure
2-2
and
proceed
as
follows:
a.
Set
the
plug-on,
on
its
feet,
on
a
flat
surface
with
the
front-panel
facing
you.
b.
Turn
the
5310A
Battery
Pack
right-side
up
(LOW
BATTERY
LAMP
on
the
left)
with
front-panel
facing
you
and
slide
the
side-casting
latches
all
the
way
to
the
rear
of
the
unit.
The
latch
handles
must
be
pressed
gently
away
from
the
center
of
the
unit
to
“unlock”
them
before
sliding
rearward.
c. With the latches extended rearward, mate
the plug-on to the 5310A Battery Pack by placing the
5310A on top of the plug-on.
d. With the 5310A properly positioned on the
plug-on and the latches fully extended rearward, an
equal space should be visible (about 1/8-inch wide)
where castings meet.
e. Press down gently on top of the 5310A and
push the left and right latches forward. Castings will
be brought together (see CAUTION in Paragraph
2-12).
f. Check the position of the latches to ensure
that castings are properly mated and latched. When
properly latched, latches should not protrude past
rear-edge of casting and there should be a paper-thin
space between plug-on and 5310A Battery Pack.
g.
Turn
the
5300A
right-side
up
with
front-
panel
facing
you
(ON-OFF-SAMPLE-RATE
on
left
side)
and
slide
the
side-casting
latches
all
the
way
to
the
rear
of
the
unit.
The
latch
handles
must
be
pressed
gently
away
from
the
center
of
the
unit
to
“unlock”
them
before
sliding
rearward.
h. With latch handles fully extended rearward,
mate the 5300A to the 5310A by placing the 5300A on
top of the Battery Pack.
i. With the latches fully extended rearward and
the 5300A properly positioned on the 5310A Battery
Pack,
an
equal
space
should
be
visible
(about
1/8-
inch wide) where castings meet.
j. Press down gently on top of 5300A casting and
push the left and right latches forward; castings will
be brought together (see CAUTION in Paragraph
2-12).
k. Check the position of the latches to ensure
that castings are properly mated and latched. When
properly latched, latches should not protrude past
rear-edge of casting and there should be a paper-thin
space between 5310A Battery Pack and 5300A.
