HP 5300A - Service Aids

1. When the selected plug-on, the 5310A Battery
Pack and the 5300A Measuring System are intercon-
nected and securely latched, perform the check-out
procedure as follows:
1. Set 5310A BATTERY-LINE-CHARGE switch
to BATTERY.
2. Turn 5300A POWER switch to ON (ccw out
of OFF) and ensure that 5310A BATTERY
LOW lamp is OFF.
3. If BATTERY LOW lamp is on, turn 5300A
POWER to OFF and connect ac power to
5300A and set 5310A BATTERY switch to
CHARGE for 18 hours minimum.
4. If unit fails to operate, check interconnection
of 5300A, 5310A, and plug-on in use (if prob-
lem persists, refer to Section V, MAINTE-
NANCE, Paragraph 5-61, HP 5310A Battery
Pack).
5. Refer to Section IX for the plug-on module
used and perform the performance check
procedures for that plug-on.
Model 5300A
Installation
6.
5300A
display
should
be
as
listed
in
the
re-
spective
plug-on
performance
check.
m.
To
separate
the
5300A, 5310A,
and
plug-on,
pull
the
two-side
casting
latches
on
the
5300A
fully
rearward,
(again
it
is
necessary
to
press
the
latch
handles
gently
away
from
the
center
of
the
unit
to
“unlock”
them).
n. When latches are fully extended rearward,
the 5300A and 5310A castings should be separated by
about 1/8-inch.
o. Lift the 5300A gently way from the 5310A.
p. To separate the 5310A Battery Pack from the
plug-on, repeat steps m, n, and o.
2-18. SERVICE AIDS (Table 2-2)
2-19. To assist you in maintaining and servicing the
5300A Measuring System mainframe, the following
list of components and equipment is recommended.
Table 2-2. Diagnostic Service Kit (HP Part No. 10548A)
Shorting Plug
Diagnostic Interface
Connector
Diagnostic Card "A"
Diagnostic Card "B"
Diagnostic Card ''C"'
Diagnostic Card "D"'
COMPONENT/EQUIPMENT
HP
PART
NO.
5080-0058, 2 ea.
05300-60004, 1 ea.
05300-20011
05300-20012
05300-20013
05300-20014
1 ea.
Implements codes on Diagnostic
Cards.
Interface between 50-pin connector
and 44-pin connector.
Provides fixed tests to check 5300A
circuits, including the display.
2-5
