Chapter 1 Performance Tests
Equipment Required
1-4 Assembly-Level Service Guide
1
Equipment Required
Table 1-1. Recommended Test Equipment
Instrument Required Characteristics Recommended Model Use
Synthesizer DC to 13 MHz HP 3325B OV, P, T
Synthesized Signal Generator 100 kHz to 2560 MHz HP 8663A OV, P, T
Pulse Generator 5 ns pulse width HP 8130A or equivalent OV, C
Sweep Oscillator 3.0 GHz HP 8340B P, T
Primary Frequency Standard
(10 MHz House Standard)
Absolute accuracy >1 x 10
-10
HP 5071A C
DC Power Supply Adjustable to 5.000V HP 6234A C
Digital Voltmeter Microvolt accuracy HP 3458A OV, C
Time Interval Calibrator Effective edge repeatability:
<10 ps
HP 59992A J06 C
Type N-to-BNC Connector — HP 1250-0780 OV, P
BNC-to-Dual Banana Plug BNC(m) to banana plug HP 11001-60001 OV, P, C T
50Ω Feedthrough (3) — HP 10100C OV, P, C
50Ω Coaxial Cable with
BNC connectors (5)
BNC(m) to BNC(m), 48 inches HP 10503A OV, P, C, T
Coaxial BNC Tee Connector — 1250-0781 P, C
P = Performance Tests
OV = Operational Verification
C = Calibration
T = Troubleshooting
Some of this equipment may no longer be available as new. Use an equivalent model number.
