HP 53131A Service Manual

Chapter 1 Performance Tests
HP 53181A Performance Test Record (Page 3 of 4)
Assembly-Level Service Guide 1-73
1
HP 53181A Performance Test Record
(Page 3 of 4)
Complete Performance Tests
Test 4: Option 015/030/050 Channel 2 Frequency Sensitivity (HP 53181A Only)
Actual Reading Specification
100 MHz–1.5 GHz (Option 015 Only)
100 MHz–2.7 GHz (Option 030 Only)
2.8–3.0 GHz (Option 030 Only)
.2–5.0 GHz (Option 050 Only)
.2–12.4 GHz (Option 124 only)
1. __________
2. __________
3. __________
4. __________
5. __________
≤ −27 dBm
≤ −27 dBm
≤ −21 dBm
≤ −23 dBm
≤ −23 dBm
Test
Number Test Description Minimum
Actual
Reading Maximum
5 Option 015/030 Channel 2
Frequency Accuracy
(HP 53181A Only)
100 MHz to 1.5 GHz Test for
Option 015 (HP 53181A):
Channel 2
Channel 2
99.999,999,93 MHz
1, 499.999,999 MHz
1. __________
2. __________
100.000,000,07 MHz
1,500.000,001 MHz
5 100 MHz to 3.0 GHz Test for
Option 030 (HP 53181A):
Channel 2
Channel 2
99.999,999,93 MHz
2,999.999,998 MHz
3. __________
4. __________
100.000,000,07 MHz
3, 000.000,002 MHz
5 200 MHz to 5.0 GHz Test for
Option 050: 4,999.999,997 MHz 5. __________ 5,000.000,003 MHz
5 200 MHz to 12.4 GHz Test
for Option 124: 12,399.999,992 6. __________ 12.400.000,008 MHz
