54
Appendix C Ports and LEDs
Ports
Console port
Every 5500 EI or 5500 SI switch has one console port on the front panel.
Table 8 Console port specifications
Item S
Connector type
RJ-45
Compliant standard
EIA/TIA-232
Transmission baud rate 9600 bps (default) to 115200 bps
Service
• Provides connection to an ASCII terminal.
• Provides connection to the serial port of a local or remote (through a
pair of modems) PC running terminal emulation program.
10/100/1000Base-T Ethernet port
Table 9 10/100/1000Base-T Ethernet port specifications
Item S
Connector type
RJ-45
Interface standard
• 10 Mbps, half/full duplex
• 100 Mbps, half/full duplex
• 1000 Mbps, full duplex
• MDI/MDI-X, auto-sensing
Max transmission distance
100 m (328.08 ft)
Transmission medium
Category-5 (or above) twisted pair cable
Standards
IEEE 802.3i, 802.3u, 802.3ab
SFP port
All 5500 EI and 5500 SI switches have SFP ports.
• For the SFP transceiver modules available for the 5500 EI switches, see "GE SFP transceiver
modules" and "FE SFP transceiver modules."
• F
or the SFP transceiver modules available for the 5500 SI switches, see "GE SFP transceiver
modules."
