HP 5500 EI series Installation Guide

55
Combo interface
• On the 5500-24G-SFP EI (2 slots) and 5500-24G-SFP EI TAA (2 slots) switch, the last eight SFP ports
and the eight 10/100/1000Base-T Ethernet ports are copper/fiber combo ports in pairs, as shown
in Table 10. T
hey form eight combo interfaces.
• On all the other 5500 EI and 5500 SI switches, the last four 10/100/1000Base-T Ethernet ports
and the four SFP ports are copper/fiber combo ports in pairs, as shown in Table 10.
They form four
combo interfaces
When one port in a pair is activated, the other port automatically shuts down. For more information
about combo interfaces, see HP 5500 EI & 5500 SI Switch Series Configuration Guides.
Table 10 Copper/fiber combo ports in pairs
Chassis SFP
p
ort 10/100/1000Base-T Ethernet
p
ort
5500-24G EI (2 slots)
5500-24G EI TAA (2 slots)
5500-24G-PoE+ EI (2 slots)
5500-24G-PoE+ EI TAA (2 slots)
5500-24G SI (2 slots)
5500-24G-PoE+ SI (2 slots)
GigabitEthernet 1/0/25 GigabitEthernet 1/0/22
GigabitEthernet 1/0/26 GigabitEthernet 1/0/24
GigabitEthernet 1/0/27 GigabitEthernet 1/0/21
GigabitEthernet 1/0/28 GigabitEthernet 1/0/23
5500-48G EI (2 slots)
5500-48G EI TAA (2 slots)
5500-48G-PoE+ EI (2 slots)
5500-48G-PoE+ EI TAA (2 slots)
5500-48G SI (2 slots)
5500-48G-PoE+ SI (2 slots)
GigabitEthernet 1/0/49 GigabitEthernet 1/0/46
GigabitEthernet 1/0/50 GigabitEthernet 1/0/48
GigabitEthernet 1/0/51 GigabitEthernet 1/0/45
GigabitEthernet 1/0/52 GigabitEthernet 1/0/47
5500-24G-SFP EI (2 slots)
5500-24G-SFP EI TAA (2 slots)
GigabitEthernet 1/0/17 GigabitEthernet 1/0/25
GigabitEthernet 1/0/18 GigabitEthernet 1/0/26
GigabitEthernet 1/0/19 GigabitEthernet 1/0/27
GigabitEthernet 1/0/20 GigabitEthernet 1/0/28
GigabitEthernet 1/0/21 GigabitEthernet 1/0/29
GigabitEthernet 1/0/22 GigabitEthernet 1/0/30
GigabitEthernet 1/0/23 GigabitEthernet 1/0/31
GigabitEthernet 1/0/24 GigabitEthernet 1/0/32
LEDs
Table 11 LEDs at a glance
LED Availabilit
y
System status LED Entire series
Power supply status LEDs
5500-24G-SFP EI (2 slots)
5500-24G-SFP EI TAA (2 slots)
