HP 5920

Field Descri
p
tion
VPN Instance
VPN to which the LDAP server belongs. If no VPN is specified, this field
displays Not configured.
LDAP Protocol Version LDAP version, LDAPv2 or LDAPv3.
Server Timeout Interval LDAP server timeout period, in seconds.
Login Account DN DN of the administrator.
Base DN Base DN for user search.
Search Scope
User DN search scope, including:
• all-level—All sub-directories.
• single-level—Next lower level of sub-directories under the base DN.
User Searching Parameters User search parameters.
User Object Class
User object class for user DN search. If no user object class is configured,
this field displays Not configured.
Username Attribute User account attribute for login.
Username Format Format for the username sent to the server.
ip
Use ip to configure the IP address and port number of the LDAP server.
Use undo ip to delete the LDAP server IP address and port number.
Syntax
ip ip-address [ port port-number ] [ vpn-instance vpn-instance-name ]
undo ip
Default
An LDAP server has no IP address.
Views
LDAP server view
Predefined user roles
network-admin
Parameters
ip-address: Specifies the IP address of the LDAP server.
port port-number: Specifies the TCP port number of the LDAP server, which is in the range of 1 to 65535
and defaults to 389.
vpn-instance vpn-instance-name: Specifies the MPLS L3VPN to which the LDAP server belongs, where
vpn-instance-name is a case-sensitive string of 1 to 31 characters. If the server is on the public network,
do not specify this option.
