HP A-MSR20 Installation Guide

28
A-MSR20-40
Figure 29 Internal architecture of the A-MSR20-40
1
3
4 5 6
2
789
(1) VCPM module slot
(2) VPM module slot
(3) Fan
(4) Front panel
(5) Power supply
(6) CF card
(7) ESM module slot 0
(8) ESM module slot 1
(9) Rear panel
