1
Product overview
This chapter discusses the chassis panels of the HP A-MSR20 Router Series models listed in Table 1. The
chassis panel views shown may differ slightly from the actual panels.
Table 1 HP A-MSR20 Router Series models
J#
Type
JF283A
A-MSR20-20
JD663B
A-MSR20-21
JF228A
A-MSR20-40
A-MSR20-20 panel views
Figure 1 A-MSR20-20 front panel
1
2
3
(1) PWR LED
(2) SYS LED
(3) ESM LED
Figure 2 A-MSR20-20 rear panel
1 2
3456789
10
(1) SIC slot 2
(3) CF card slot
(4) USB port
(6) Console port
(7) Ethernet WAN ports
(ETH0 and ETH1)
(9) Power receptacle
(10) Grounding screw
