3
Figure 6 A-MSR20-40 rear panel
1 2
3456
(1) SIC slot 4
(2) SIC slot 3
(3) Ethernet WAN ports
(ETH0 and ETH1)
(4) SIC slot 1
(5) SIC slot 2
(6) Grounding screw
