HP A5120 EI Series

58
(3) Console port
(4) Port LED
(5) Power LED (Power)
Figure 61 Rear panel
1 2
(1) AC-input power receptacle
(2) Grounding screw
A5120-24G SI
Figure 62 Front panel
1 2 3 4 5
(1) 10/100/1000Base-T auto-sensing Ethernet port
(2) 1000Base-X SFP port
(3) Console port
(4) Port LED
(5) Power LED (Power)
Figure 63 Rear panel
1 2
(1) AC-input power receptacle
(2) Grounding screw
A5120-48G SI
Figure 64 Front panel
1 2 3
456
(1) 10/100/1000Base-T auto-sensing Ethernet port
(2) 10/100/1000Base-T Ethernet port LED
