HP A5120 EI Series Installation Guide

66
GE SFP transceiver modules
IMPORTANT:
You must use the transceiver modules coded JD098B and JD099B in pairs.
Product
code
Module description
Central
wavelength
(nm)
Cable/fiber
diameter
(µm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max
transmission
distance
JD118B
HP X120 1G SFP LC SX
Transceiver
850
50/125
500
550 m
(1804.46 ft)
400
500 m
(1640.42 ft)
62.5/125
200
275 m
(902.23 ft)
160
220 m
(721.78 ft)
JD119B
HP X120 1G SFP LC LX
Transceiver
1310
9/125
N/A
10 km (6.21
miles)
50/125
500, 400
550 m
(1804.46 ft)
62.5/125
500
550 m
(1804.46 ft)
JD061A
HP X125 1G SFP LC
LH40 1310nm
Transceiver
1310
9/125
N/A
40 km (24.86
miles)
JD062A
HP X120 1G SFP LC
LH40 1550nm
Transceiver
1550
9/125
N/A
40 km (24.86
miles)
JD063B
HP X125 1G SFP LC
LH70 Transceiver
1550
9/125
N/A
70 km (43.50
miles)
JD103A
HP X120 1G SFP LC
LH100 Transceiver
1550
9/125
N/A
100 km
(62.14 miles)
JD098B
HP X120 1G SFP LC BX
10-U Transceiver
TX: 1310nm
RX: 1490nm
9/125
N/A
10 km (6.21
miles)
JD099B
HP X120 1G SFP LC BX
10-D Transceiver
TX: 1490nm
RX: 1310nm
9/125
N/A
10 km (6.21
miles)
JD089B
HP X120 1G SFP RJ45 T
Transceiver
N/A
Category-5
twisted pair
N/A
100 m
(328.08 ft)

HP A5120 EI Series Specifications

General

Uplink Ports	4 x SFP
Stacking	No
Management	CLI, Web, SNMP
Routing Protocols	RIP, OSPF
Power Supply	AC
MAC Address Table Size	16K
Dimensions	440 x 430 x 44 mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Model	HP A5120-24G EI Switch (JG234A)
VLANs	4094
