HP A5120 EI Series

78
Table 31 Ethernet port LED description (A5120-48G SI)
Status
Description
Steady green
The port is operating at 1000 Mbps.
Fast flashing green
The port is sending or receiving data at 1000 Mbps.
Steady yellow
The port is operating at 10/100 Mbps.
Fast flashing yellow
The port is sending or receiving data at 10/100 Mbps.
Off
No link is present on the port.
Table 32 Ethernet port LEDs description (A5120-16G SI/A5120-24G SI)
LED
Status
Description
Green
On
The port is operating at 1000 Mbps.
Fast flashing
The port is sending or receiving data at 1000
Mbps.
Off
The port has no link or is not operating at 1000
Mbps.
Yellow
On
The port is operating at 10/100 Mbps.
Fast flashing
The port is sending or receiving data at 10/100
Mbps.
Off
The port has no link or is not operating at
10/100 Mbps.
Table 33 Ethernet port LED description (A5120-24G-PPoE+ SI/A5120-24G-PoE+ SI)
Port mode LED
(Mode) status
Port LED
Port LED status
Description
Steady green (rate
mode)
Green
On
The port is operating at 1000 Mbps.
Fast flashing
The port is sending or receiving data at 1000
Mbps.
Off
The port has no link or is not operating at
1000 Mbps.
Yellow
On
The port is operating at 10/100 Mbps.
Fast flashing
The port is sending or receiving data at
10/100 Mbps.
Off
No link is present on the port.
Flashing green (PoE
mode)
Green
On
PoE power supply is normal.
Flashing at 3 Hz
The device attached to the port requires
power higher than the maximum or currently
available PoE output power on the port.
Off
The port is not supplying power.
Yellow
On
Off
