LEDs, Switches, and Jumpers
Table E-2: Rear Panel LED Indicators continued
Location LED Status
3 Rear unit identification
LED switch
On = Local
Management
Blinking = Remote
Management
Off = Deactivated
System Board LEDs
The system board contains various LEDs which display current conditions of the
server. These are identified in the illustration below and in Table E-3.
Figure E-3: Locating the system board LEDs and
switches
HP ProLiant DL320 Generation 2 Server Setup and Installation Guide E-5
HP CONFIDENTIAL
Writer: Anna Roberts File Name: o-appe LEDs, Switches and Jumpers.doc
Codename: MoonStar Part Number: 293166-002 Last Saved On: 1/31/03 11:22 AM
