Installing Hardware Options
Installing the Expansion Board
To install an expansion board:
1. Remove the expansion slot cover by pressing outward on its inner face.
Figure 3-6: Removing the expansion slot cover
CAUTION: Do not discard the expansion slot cover. If the PCI expansion board is
removed in the future, the expansion slot cover must be reinstalled to maintain
proper cooling.
3-10 HP ProLiant DL320 Generation 2 Server Setup and Installation Guide
HP CONFIDENTIAL
Writer: Anna Roberts File Name: d-ch3 Installing Hardware Options.doc
Codename: MoonStar Part Number: 293166-002 Last Saved On: 1/31/03 11:16 AM
