LEDs, Switches, and Jumpers
When adding or removing a component or changing a security feature, the server
must be reconfigured to recognize these changes. If the system configuration is
incorrect, the server may not work properly, and you may receive error messages on
the screen.
IMPORTANT: Reserved switches are provided for use by authorized service providers only
and should not be changed from the indicated default settings.
Refer to Figure E-3 and Table E-3 for location on the system board of the System
Configuration Switch.
The following subsections provide reference information about setting the system
board switches and jumpers, which is part of the reconfiguration process, along with
running the ROM-Based Setup Utility (RBSU).
System Configuration Switch (SW1)
The system configuration switch (SW1) is an eight-position switch used for system
configuration. Refer to the labels attached to the inside of the server access panel for
the proper system configuration switch settings. The following table shows the
shipping configuration of SW1.
