3.5-inch Hard Drive
1. Prepare the computer for disassembly (Preparation for Disassembly on page 56).
2. Remove the access panel (
Access Panel on page 57).
3. Disconnect the power and data cables from the back the drive.
4. Remove the four retaining screws that secure the drive to the bay (1).
5. Slide the drive back and out of the bay (2).
To install a new hard drive, reverse the removal procedure.
Drives 71
