4-63

Web and MAC Authentication

Configuring MAC Authentication on the Switch

Using the Restrictive-Filter Option

The restrictive-filter option allows the switch to reply to all HTTP requests to

the switch’s IP address with an HTTP-redirect containing the URL of the

registration server. It is used when there is no registration process and only a

warning or informational page is displayed to the client.

If SSL is not configured, the switch verifies that the MAC address and interface

port parameters are present. If SSL is enabled, the switch ensures that the

HTTP request is to the registration server’s destination IP address.

Show Command Output

Figure 4-39 is an example of the show command that displays the HTTP

redirect configuration.

Figure 4-39. Example of HTTP Redirect Configuration

Reauthenticating a MAC-Auth Client

Using SNMP. The MIB variable hpicfUsrAuthMacAuthClientReauthentica-

teEntry in the hpicfUsrAuthMIB provides the capability to reauthenticate a

specific MAC-auth client on a port. The MAC address and port are required

for SNMP reauthentication.

HP Switch(config)# show port-access mac-based config

Port Access MAC-Based Configuration

MAC Address Format : no-delimiter

Unauth Redirect Configuration URL : http://14.29.16.192:80/myserver.html

Unauth Redirect Client Timeout (sec) : 1800

Unauth Redirect Restrictive Filter : Disabled

Total Unauth Redirect Client Count : 1

Client Client Logoff Re-Auth Unauth Auth Cntrl

Port Enabled Limit Moves Period Period VLAN ID VLAN ID Dir

----- -------- ------ ------ --------- --------- -------- -------- -----

1 No 1 No 300 0 0 0 both

2 No 1 No 300 0 0 0 both

3 No 1 No 300 0 0 0 both

4 No 1 No 300 0 0 0 both

Configured HTTP redirect URL
