4-59

Web and MAC Authentication

Configuring MAC Authentication on the Switch

Figure 4-37. Example of Running Configuration Output When RADIUS Response is Configured

HTTP Redirect When MAC Address Not Found

When a client’s MAC address is checked by the RADIUS server against the

known list of MAC addresses, and the MAC address is not found, the client

needs a way to quickly become registered through a web registration process.

The HTTP Redirect feature provides a way for a client who has failed MAC

authentication to become registered through a web/registration server. Only

a web browser is required for this authentication process.

HP Switch(config)# show running-config

Running configuration:

; J9573A Configuration Editor; Created on release #KA.15.03.3003

; Ver #01:00:01

hostname "HP Switch"

module 1 type J9573x

web-management ssl

qos dscp-map 000000 priority 0

no stack auto-join

vlan 1

name "DEFAULT_VLAN"

untagged 1-14,19-24

ip address dhcp-bootp

no untagged 15-18

exit

vlan 100

name "auth-vid"

untagged 15-18

ip address dhcp-bootp

exit

radius-server host 10.0.13.118 key 'secret'

aaa authentication port-access eap-radius

snmp-server community "public" Unrestricted

aaa port-access web-based 5

aaa port-access web-based 5 auth-vid 100

aaa port-access web-based 5 unauth-vid 1

aaa port-access web-based dhcp-addr 172.18.0.0 255.255.255.0

aaa port-access web-based access-denied-message radius-response

RADIUS response configured
