6-72

RADIUS Authentication, Authorization, and Accounting

Dynamic Removal of Authentication Limits

Settings for these VSAs are in effect for the duration of the authenticated

session of the downstream supplicant switch. If for any reason there is a loss

of the session (link loss between authenticator switch and supplicant switch,

or authentication failure during reauthentication), the originally configured

802.1X and MAC authentication limits are restored.

Displaying the Port-access Information

The show port-access summary command displays the dynamically changed

client limit settings.

Note If the command no aaa port-access authentication <port-list> client-limit is exe-

cuted, the port access is in port-mode. If the 802.1X client-limit is configured

with a value from 1-32, the port access is in user-mode.

Figure 6-34. Example of Summary Configuration Information Showing RADIUS Overridden Client Limits

Syntax: show port-access summary [radius-overridden]

Displays summary configuration information for all ports,

including the ports that have client limits set by RADIUS

VSAs.

radius-overridden: Displays only the ports with client limits

that are overridden by RADIUS attributes.

HP Switch(config)# show port-access summary

Port Access Status Summary

Port-access authenticator activated [No] : No

Allow RADIUS-assigned dynamic (GVRP) VLANs [No] : No

Note: * indicates values dynamically overridden by RADIUS

Authenticator Web Auth MAC Auth

Port Enabled Mode Limit Enabled Limit Enabled Limit

---- + ------- ---- ----- + ------- ----- + ------- -----

1 | Yes user* 1* | Yes 1 | Yes 1

2 | Yes user 32 | Yes 32* | Yes 32

3 | Yes port 1 | No 1 | No 1

4 | No port 1 | No 1 | No* 1
