10-66

IPv4 Access Control Lists (ACLs)

Configuring Extended ACLs

[ tos < tos-setting > ]

This option can be used after the DA to cause the ACE to match

packets with the specified Type-of-Service (ToS) setting. ToS

values can be entered as the following numeric settings or, in

the case of 0, 2, 4, and 8, as alphanumeric names:

0 or normal

2 “ max-reliability

4 “ max-throughput

8 “ minimize-delay

Note: The ToS criteria in this section are applied in addition

to any other criteria configured in the same ACE.

[log]

This option can be used after the DA to generate an Event Log

message if:

• The action is deny. (Not applicable to permit.)

• There is a match.

• ACL logging is enabled. (Refer to “Enabling ACL Logging

on the Switch” on page 10-114.)
