13-66
Configuring Port-Based and User-Based Access Control (802.1X)
Displaying 802.1X Configuration, Statistics, and Counters
Table 13-2. Output for Determining Open VLAN Mode Status (Figure 13-18, Lower)
Status Indicator Meaning
Status Closed: Either no client is connected or the connected client has not received authorization through
802.1X authentication.
Open: An authorized 802.1X supplicant is connected to the port.
Current VLAN ID < vlan-id >: Lists the VID of the static, untagged VLAN to which the port currently belongs.
No PVID: The port is not an untagged member of any VLAN.
Current Port CoS Refer to the section describing RADIUS support for Identity-Driven
Management—IDM—in chapter 6, “RADIUS Authentication, Authorization,
and Accounting” in this guide.
% Curr. Rate Limit
Inbound
Syntax: show vlan < vlan-id >
Displays the port status for the selected VLAN, including an
indication of which port memberships have been temporarily
overridden by Open VLAN mode.
