Access Panel
Description Spare part number
Access panel 646815-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 163).
2. If the computer is on a stand, remove the computer from the stand.
3. Lift up on the access panel handle (1) then lift the access panel off the computer (2).
Figure 8-1 Removing the access panel
To install the access panel, reverse the removal procedure.
164 Chapter 8 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
