Changing from Desktop to Tower Configuration
1. Prepare the computer for disassembly (Preparation for Disassembly on page 207).
2. Orient the computer so that its left side is facing down and place the computer firmly down into
the stand.
Figure 9-44 Placing the computer on the stand
3. Reconnect the external equipment, plug the power cord into a power outlet, and turn the
computer on.
4. Lock any security devices that were disengaged when the computer cover or access panel was
removed.
To change from the tower configuration to the desktop configuration, reverse the previous steps.
NOTE: An optional Quick Release mounting bracket is available from HP for mounting the computer
to a wall, desk, or swing arm.
248 Chapter 9 Removal and Replacement Procedures Ultra-Slim Desktop (USDT) Chassis
