Processor
Description Spare part number
Intel Core i7 processor
3770s, 3.4 GHz, 8-MB L3 cache 689370-001
Intel Core i5 processors
3550s, 3.1 GHz, 6-MB L3 cache 689371-001
3475s, 2.9 GHz, 6-MB L3 cache 695078-001
3470s, 2.9 GHz, 6-MB L3 cache 695077-001
Intel Core i3 processors
2130, 3.4 GHz, 3-MB L3 cache 665120-001
2120, 3.3 GHz, 3-MB L3 cache 638629-001
Intel Pentium processors
G870, 3.0 GHz, 3-MB L3 cache 691936-001
G860, 3.0 GHz, 3-MB L3 cache 665123-001
G640, 2.8 GHz, 3-MB L3 cache 691935-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 207).
2. Remove the computer access panel (
Access Panel on page 208).
3. Remove the heat sink (
Heat sink on page 231).
4. Rotate the processor locking lever to its full open position (1).
5. Raise and rotate the microprocessor retainer to its fully open position (2).
Processor 233
