Table 3-2 Display component descriptions and part numbers
Item Component Spare part number
(1) Display bezel:
For use on computer models equipped with a display panel with an infrared webcam and ALS N18755-001
For use on computer models equipped with a display panel with an infrared webcam N09021-001
For use on computer models equipped with a display panel with an RGB webcam and ALS N18756-001
For use on computer models equipped with a display panel with an RGB webcam N09022-001
For use on computer models equipped with a microphone N09023-001
(2) Display hinge cover: The display hinge cover is included in the Display Hinge Kit, spare part number N09028-001.
(3) Display Hinge Kit (includes display hinge cover and left and right display hinges) N09028-001
(4) Display panel:
35.6 cm (14.0 in), LCD, WUXGA (1920 × 1200), antiglare, LED, UWVA, 45% CG, eDP without PSR, bent,
TOP display panel; typical brightness: 250 nits
M99947-005
35.6 cm (14.0 in), LCD, WUXGA (1920 × 1200), antiglare, LBL, UWVA, 45% CG, eDP 1.4 + PSR, bent,
non-TOP display panel; typical brightness: 250 nits
N99948-005
Display assembly subcomponents 23
