To install the speakers, reverse the removal procedure.
Connector board cable
To remove the connector board cable, use this procedure and illustration.
NOTE: The connector board cable is included in the Cable Kit, spare part number N18760-001.
Before removing the connector board cable, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 39).
2. Remove the bottom cover (see Bottom cover on page 39).
3. Disconnect the battery cable from the system board (see Battery on page 41).
Remove the connector board cable:
1. Release the zero insertion force (ZIF) connector (1) to which the connector board cable is connected, and
then disconnect the cable from the system board.
2. Release the ZIF connector (2) to which the connector board cable is connected, and then disconnect the
cable from the system board.
50 Chapter 5Removal and replacement procedures for authorized service provider parts
