8.
Rotate the EMI filler panels and the optical drive 90 degrees as shown in the figure below, and
then reinstall them (see
Installing an optical drive (desktop configuration) on page 94.
Figure 5-88 Reinstalling the optical drive
9.
Replace the front bezel (see
Installing the front bezel on page 82) and the side access panel (see
Installing the side access panel on page 77) when finished.
Product recycling
HP encourages customers to recycle used electronic hardware, HP original print cartridges, and
rechargeable batteries.
For information about recycling HP components or products, see
http://www.hp.com/go/recycle.
162 Chapter 5 Replacing components ENWW
