Workstation specifications
This section provides workstation chassis, power supply, and environmental specifications.
Physical characteristics
The following table lists the workstation physical characteristics.
Weight (Typical configuration)
13.5-19.6 kg (29.8-43.2 lb.)
Chassis Dimensions Height: 45.0 cm (17.7 in.)
Width: 17.0 cm (6.7 in.)
Depth: 44.5 cm (17.5 in.)
Power supply description
The workstation includes a 475-W 85% efficient power supply to provide power for the workstation.
The power supply is compatible with ENERGY STAR requirements.
Power supply voltages
Table 1-4 Power supply source voltages
Source voltage Description
+3.3V PCI, PCIe, audio, clocks, chipset, super I/O, BIOS ROM, and onboard logic
+5.1V Storage (hard disk drive, optical disk drive, diskette drive), PCI, PCIe,
chipset, audio, keyboard/mouse, and USB
+12 V-CPU Input to onboard regulator that supplies power to CPU and CPU fan
+12 V-B PCI, PCIe, and system fans
+12 V-D Storage (hard disk drive, optical disk drive, diskette drive), graphics
adapter, and input to onboard regulator that supplies power to memory
V12N PCI and serial ports
+5 V-SB Sleep circuitry
8 Chapter 1 Product overview ENWW
