Item Description Status Definition
O Deactivated
2 Node 1 UID button/LED
1
Solid blue Activated
Flashing blue • 1 flash per second = Remote management
or firmware upgrade in progress
• 4 flashes per second = iLO manual soft
reboot sequence initiated
• 8 flashes per second = iLO manual hard
reboot sequence in progress
O Deactivated
3 Node 2 Health LED
1, 2
Solid green Normal
Flashing green iLO rebooting
Flashing amber System degraded
2
Flashing red System critical
2
4 Node 1 Health LED
1, 2
Solid green Normal
Flashing green iLO rebooting
Flashing amber System degraded
2
Flashing red System critical
2
5 Node 4 Health LED
1, 2
Solid green Normal
Flashing green iLO rebooting
Flashing amber System degraded
2
Flashing red System critical
2
6 Node 3 Health LED
1, 2
Solid green Normal
Flashing green iLO rebooting
Flashing amber System degraded
2
Flashing red System critical
2
7 Node 4 UID button/LED
1
Solid blue Activated
Flashing blue • 1 flash per second = Remote management
or firmware upgrade in progress
• 4 flashes per second = iLO manual soft
reboot sequence initiated
• 8 flashes per second = iLO manual hard
reboot sequence in progress
O Deactivated
8 Node 3 UID button/LED
1
Solid blue Activated
Table Continued
