• PIB for Performance power supplies
To replace the component, reverse the removal procedure.
Removing and replacing the power backplane
CAUTION: Before replacing a DIMM, expansion card, or other similar PCA components due to a perceived hardware
error, make sure first that the component is firmly seated in the slot. Do not bend or flex circuit boards when
reseating components.
Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• T-10 Torx screwdriver
• T-15 Torx screwdriver
Procedure
1.
Power down the servers.
2. Remove all power:
Removal and replacement procedures
56
