Drive backplane cabling
The drive backplane cabling images in this section show the following:
• Drive power connections from the fan board to the drive backplane.
• Server node signal connections from the system interconnect posts to the drive backplane.
n2600 8 SFF U.3 drive backplane cabling
Drive power cabling
Cable color Description
Pink Drive box 1 power cable
Gold Drive box 2 power cable
Blue Drive box 3 power cable
Orange Drive box 4 power cable
Server node signal cabling
Cabling
91
