HPE InfiniBand HDR/Ethernet 940QSFP 56x16 adapter LEDs
Link LED status
1
Description
O A link has not been established.
Solid amber Active physical link exists
Blinking amber 4 Hz blinking amber indicates a problem with the physical
link.
Solid green A valid logical (data activity) link exists with no active
traic.
Blinking green A valid logical link exists with active traic.
1
2-port adapter LEDs are shown. The 1-port adapters have only a single LED.
DSC-252-port SFP28 card ports and LEDs
Ports
Component identification
33
